DNSBL check order

​
Overview

The Dnsbl section provides domain blocking, category-based routing, and DNS-based blacklisting to prevent access to malicious or unauthorized websites.

​
Core Mechanics (C++ Source Validation)

  • Sequential Heuristics: The DNSBL module does not just check lists; it runs a sequence of heuristic checks on the HTTP Host header (including length validation, homograph detection, and category/request structural checks).
  • Enforcement & Block Status: If any heuristic or blocklist check fails, the connection action is instantly set to DO NOT BYPASS. SafeSquid sets the HTTP status to LMS_MALICIOUS_SERVER, terminates the forward connection, and serves the specified Template to the client.
  • Bypass Checking: The entire module execution is skipped if the connection carries the FEATURE_DNSBL bypass right, or if the request is destined for the SafeSquid interface itself.

​
Schema Fields

​
Global Fields

  • Enabled (enabled): When off, DNSBL/category/country/IP checks in this section are skipped. When on, uncategorized-domain heuristics run first, then policy rows.
  • Maximum Permissible Unique Hosts In An Uncategorized Domain (limit): Before policy rows, block hosts in an uncategorized registered domain when unique host count under that domain exceeds this value. Legacy UI allows -1 to disable; verify behaviour in your build if you rely on that value.
  • Maximum Permissible Host Name Length In An Uncategorized Domain (namelegth): Before policy rows, block when the host label length in an uncategorized domain exceeds this limit. Legacy UI allows -1 to disable; verify behaviour in your build if you rely on that value.
  • Block Homograph based Uncategorized Domain (homograph): When on, block hosts in uncategorized domains whose registered domain contains confusable (homograph) characters.

​
Rule-Based Fields (Per Connection Tuning)

  • Enabled (enabled): Skip this policy row when disabled.
  • Comment (comment): Notes for operators. Used as block reason when non-empty (category/request blocks).
  • Threatful Categories (bl_categories): Block when the connection’s website categories include any listed category. No DNS lookup. First matching policy row wins within this check.
  • Threatful Requests (bl_requests): Block when the connection’s request types include any listed type. No DNS lookup. First matching policy row wins within this check.
  • Threatful Countries (bl_countries): After resolving the host A record, block when GeoIP country code is in this list. Requires a successful A lookup and runs inside the IP-check pass.
  • DNSBL Domain (domain): Suffix appended to the request host for DNSBL lookup (for example example.com.in.dnsbl.org ). Leave empty on rows that only use category/request/country/IP list checks.
  • Blocked IP addresses (badips): IPs that count as a DNSBL hit. Compared against: host A record, reverse-DNSBL answer, or direct IP match. Failed DNSBL lookups are treated as 0.0.0.0 ; include that address to block lookup failures.
  • Template (templ): Block page template when this row triggers a block. Blank uses blocked (request-type rows may append the match name).

​
How SafeSquid processes checks

  1. When website categories are empty, uncategorized heuristics run: host name length, homograph, then unique-host count under the registered domain.
  2. Category check: walk policy rows top to bottom; first row whose Threatful Categories match any connection category blocks immediately (no DNS).
  3. Request type check: same first-match walk against Threatful Requests.
  4. DNSBL check: append DNSBL Domain suffix to the request host, resolve A record, compare to Blocked IP addresses. Failed lookups are treated as 0.0.0.0 — include that address to block lookup failures.
  5. IP check: compare host A record, reverse DNSBL answer, and GeoIP country (Threatful Countries) against Blocked IP addresses / country list — first block in each sub-pass wins.
  6. On block: action DO NOT BYPASS, block template, debug header X-DNSBL-Filter with match detail.

​
Important entry fields

  • Threatful Categories — Block when the connection’s website categories include any listed category. First matching policy row wins.
  • Threatful Requests — Block when the connection’s request types include any listed type. First matching row wins.
  • DNSBL Domain — Suffix appended to the request host (for example example.com.in.dnsbl.org). Leave empty on rows that only use category/request/country/IP checks.
  • Blocked IP addresses — IPs that count as a DNSBL hit (ranges supported). Compared against lookup answers and direct host A records.
  • Threatful Countries — After resolving the host A record, block when GeoIP country code is in this list.
  • Template — Block page when this row triggers. Blank uses blocked (request-type rows may append the match name).

​
Examples

Open Configure → Real time content security → DNS Blacklist → DNS and IP Black Listing Policies. Row fields are Enabled, Comment, and Threatful Categories (or Threatful Requests) — the top row in the capture below is hidden since its category list names a CSAM category not suitable to publish verbatim; the remaining rows show the field shape clearly.

DNS Blacklist — DNS and IP Black Listing Policies rows

​
1 — Block malware category without DNS

  • Policy row: Threatful Categories includes Malware
Result: any connection already tagged with Malware is blocked immediately with HTTP 451 and the row template; no DNSBL query runs for that decision.

​
2 — DNSBL listed host

  • DNSBL Domain: .in.dnsbl.org
  • Blocked IP addresses: 0.0.0.0,127.0.0.1-127.0.0.6
Result: SafeSquid looks up <host>.in.dnsbl.org; if the A record is in the blocked list (including 0.0.0.0 on failure), the request is blocked before fetch.

​
3 — Long hostname on uncategorized site

  • Maximum host name length: 5
  • Site has no categories yet; host verylonglabel.example
Result: name-length heuristic blocks with reason about uncategorized host length; policy rows are not reached for that connection.

​
4 — Trusted users skip DNSBL

  • Access Allow entry with Bypass → DNS Blacklist
Result: matching clients skip the entire DNSBL module; other users still run category, DNSBL, and IP checks.

​
How to verify

  1. Request a known-listed or test host and confirm HTTP 451 block page.
  2. Check debug response header X-DNSBL-Filter (category name, Request/…, DNSBL host/IP, or heuristic reason).
  3. Enable SECURITY in LOG_LEVEL for native dnsbl / blocked lines.
  4. Open Reports → Detailed logs; filter_name shows dnsbl with filtering reason.
